Industrial Laser Marking CO2 Laser Printer
Features:
- Great stability with high precision Intelligent circuit control
- Clear and unerasable marking Used for high speed production line
- Low cost for maintenance
- Easy to operate with an advantages of long life time
Mainly apply to the packaging industry, such as food, medicine, beverage, daily use chemical and so on. Suitable for various kinds of material, like paper, wood, glass, ceramics, plastics, aluminum foil, leather, etc.
Product parameter:
Item Type Model | CP6020C | CP6030C | CP6060C |
Machine material | Aluminum structures+Stainless steel | ||
Laser | CO2 laser generator | ||
Output Power | 20W | 30W | 60W |
Laser wave Length | 10.6μm /10.2μm/9.6μm | 10.6μmm | |
Lens | High precision 2 dimensional scanning system | ||
Marking speed | ≤8000mm/S | ≤1200mm/S | |
Main controller system | Highly integrated main board,Embedded 10.4 inch controller | ||
Cooling system | Air cooled | ||
Focus zoom lens | 130mm double red light focusing | ||
Marking scale type | Raster font, vector font for choosing | ||
Min.line width | 0.03mm | ||
Repeatability accuracy | 0.01mm | ||
Working area | 110×110mm | ||
Positioning | Red light positioning and double red light focusing | ||
Lines of marking | No limited in working area | ||
Speed | 0-200m/min | 0-230m/min | |
Power | 220VA | ||
Power Consumption | 800W | 1200W | |
